Chamfering Machine

30T edge beveling machine is a table-type machine designed specifically for heavy, short, and thick metal plates, ideal for weld beveling. It offers a wide working range with the ability to clamp thicknesses ranging from 8mm to 80mm. The bevel angle is easily adjustable between 10 to 75 degrees, ensuring versatility and adaptability. The machine operates with high efficiency, providing precise results with a surface finish of Ra 3.2-6.3.

Features

1.Compatible with various metal plates, including carbon steel, stainless steel, aluminum, and more.

2.Capable of processing different types of bevel joints, such as "V" and "Y."

3.Utilizes milling technology with high precision, achieving a surface finish of Ra 3.2-6.3.

4.Cold cutting technology for energy efficiency, low noise operation, and enhanced safety with overload protection.

5.Offers a wide working range, accommodating material thicknesses ranging from 8mm to 80mm and adjustable bevel angles from 10 to 75 degrees.

6.User-friendly operation for high efficiency.

7.Specially designed for heavy-duty metal plate applications.
